    Self-Adhesive Polymer Modified Asphalt Waterproofing Membrane

    Ask Lasest Price
    Brand Name : JOINSUN
    Model Number : 1.5mm、2mm、3mm、4mm
    Certification : GB18242-2008
    Price : $2-10/㎡
    Supply Ability : 50 million square meters per year
    Delivery Time : 5-8 weeks
    • Product Details
    • Company Profile

    Self-Adhesive Polymer Modified Asphalt Waterproofing Membrane

    Product Overview

    Self-adhesive polymer modified asphalt waterproofing membrane (hereinafter referred to as Type N) is made with synthetic rubbers such as SBS, high-quality road asphalt and tackifiers as the base materials. The upper surface materials are polyester film (PET), polyethylene film (PE), aluminum foil or silicone-coated release film, and the lower surface is covered with a silicone-coated release film as the anti-adhesive layer, thus forming a self-adhesive polymer modified asphalt waterproofing membrane without a base layer.

    Self-adhesive polymer modified asphalt polyester-felt waterproofing membrane (hereinafter referred to as Type PY) takes the continuous filament polyester mat as the base layer, and the tackifying polymer modified asphalt as the impregnating and coating material. The surface is covered with polyethylene film, fine sand, shale, aluminum foil or a release film as the isolation layer, and the lower surface is covered with a silicone-coated release film as the anti-adhesive layer, thereby forming a self-adhesive polymer modified asphalt polyester-felt waterproofing membrane.

    Product Feature

    • The special formula and unique manufacturing process make it have the characteristics of cold construction, no use of open flames, no use of adhesives, and no pollution to the environment.
    • Polyester felt has high tensile strength, high elongation, and strong adaptability to base shrinkage, cracking, and deformation.
    • Using SBS modified asphalt as coating material, it has good high and low temperature resistance and meets the needs of exposed waterproof layer.
    • Good bonding performance, synchronized with the service life of the roll material and the self bonding of the roll joint.
    • The self-adhesive rubber asphalt on the lower surface of the coil is coated in regular strips to bond with the base layer, which has a unique function.
    • Form a steam exhaust channel to balance the steam pressure at the base layer and avoid bulging of the waterproof layer.
    • During shrinkage, cracking, and deformation of the base layer, it can avoid cracking caused by the "zero extension" phenomenon of the waterproof layer due to full adhesion between the waterproof layer and the base layer.


    Main physical and mechanical properties of Class N

    S/NPROJECTINDEX
    PEPETD
    1Tensile PropertyTensile force/(N/50MM) ≥150200150200−−
    Elongation rate at maximum tension/% ≥20030−−
    Asphalt fracture elongation rate/% ≥250150450
    Phenomenon during stretchingDuring the stretching process, there is no asphalt coating or membrane splitting phenomenon before the membrane fractures.−−
    2Tear strength of nail rod/N ≥601103040−−
    3Heat ResistanceSliding at 70 ℃ not exceeding 2mm
    4Low temperature flexibility/℃-20-30-20-30-20
    No cracks
    5Impermeability0.2MPa, impermeable for 120min−−
    6Peel strength/(N/mm)≥coiled material and coiled material1.0
    Coiled material and aluminum plate1.5
    7Watertightness of nail rodPass through
    8Oil leakage/number of sheets ≤2
    9Holding viscosity/min ≥20
    10Thermal AgeingTensile retention rate/%>80
    Elongation rate at maximum tension/% ≥20030400
    Low temperature flexibility/℃-18-28-18-28-18
    No cracks
    Peel strength coil and aluminum plate/(N/mm) ≥1.5
    11Thermal stabilityAppearanceNo bulging, No wrinkling, No sliding, No flowing
    Size change/% ≤2

    Main physical and mechanical properties of Class PY

    S/NPROJECTINDEX
    1Soluble content (g/㎡) ≥2.0mm1300− −
    3.0mm2100
    4.0mm2900
    2Tensile PropertyTensile strength (N/50mm) ≥2.0mm350− −
    3.0mm450600
    4.0mm450800
    Elongation rate at maximum tension/% ≥3040
    3Heat Resistance70 ℃ without sliding, flowing, or dripping
    4Low temperature flexibility/℃-20. No cracks-30. No cracks
    5Impermeability0.3MPa, impermeable for 120min
    6Peel strength/(N/mm)≥coiled material and coiled material1.0
    Coiled material and aluminum plate1.5
    7Watertightness of nail rodPass through
    8Oil leakage/number of sheets ≤2
    9Holding viscosity/min ≥15
    10Thermal AgeingElongation rate at maximum tension/% ≥3040
    Low temperature flexibility/℃-18-28
    No cracks
    Peel strength coil and aluminum plate/(N/mm) ≥1.5
    Dimensional stability/% ≤1.51.0
    11Self adhesive asphalt re stripping strength (N/mm) ≥1.5

    Application scope

    • Building roof waterproofing: Widely used in roof waterproofing projects of various industrial and civil buildings, including flat roofs and sloping roofs, etc., which can effectively prevent rainwater leakage and protect the internal structure of buildings.
    • Underground waterproofing projects: Applicable to waterproofing and moisture-proofing of underground projects such as basements, underground garages, and tunnels. It can resist the penetration of groundwater and ensure the dryness and safety of underground spaces.
    • Waterproofing of special parts: It can also be used in indoor spaces with waterproofing requirements such as bathrooms, showers, and kitchens, as well as waterproofing of hydraulic structures such as pools, swimming pools, and water towers. It can meet the waterproofing needs of different parts.
